PREMIUM CREATING ULTIMATE EXPERIENCE SINOTRUK ratified strategic cooperative agreement with German MAN, initiating all-round in-depth cooperation from every aspect, and introduced a whole package of key assembly and part-related technology in the respect of its cab, chassis, axle and engine etc. In 2011, SINOTRUK launched SITRAK, a new generation of heavy truck in line with European quality standard.
PREMIUM CREATING ULTIMATE EXPERIENCE
SINOTRUK ratified strategic cooperative agreement with German MAN, initiating all-round in-depth cooperation from every aspect, and introduced a whole package of key assembly and part-related technology in the respect of its cab, chassis, axle and engine etc. In 2011, SINOTRUK launched SITRAK, a new generation of heavy truck in line with European quality standard.
HIGH RELIABILITY
Introduce the original German MAN TG series vehicle technology, the same product design and the same production assembly technology, completely adopt the German standard in the production conformity management, testing & validation and the product release, and synchronize the parts purchasing system with MAN company, allof which are the strong guarantee of the vehicle high reliability.
DIMENSI / DIMENSION | |
---|---|
Panjang / Overall Length [OAL] | 7.175 mm |
Lebar / Overall Width [OW] | 2.513 mm |
Tinggi / Overall Height [OH] | 3.330 mm |
Jarak Sumbu / Wheelbase [WB] | 3,600 + 1,415 mm |
Julur Depan / Front Overhang [FOH] | 1.475 mm |
Julur Belakang / Rear Overhang [ROH] | 725 mm |
Jarak Terendah ke Tanah / Minimum Clearance [HH] | 186 mm |
Jejak Depan / Front Tread [AW] | 2.055 mm |
Jejak Belakang / Rear Tread [CW] | 1.850 mm |
Ukuran Badan / Body Dimensions | - |
MESIN / ENGINE | |
Model | MC13.54-50 |
Tipe / Type | 4 Stroke Direct Injection Diesel Engine 6 cylinder in line with water cooling, Intercooler Turbocharged |
Sistem Kontrol Emisi | EURO 5 |
Jumlah Silinder / No. of Cylinders | 6 |
Diameter x Langkah / Bore x Stroke | 126 X 166 mm |
Isi Silinder / Piston Displacement | 12.419 cc |
Tenaga Maksimum / Maximum Power | 540 / 2,500 HP/rpm |
Torsi Maksimum / Maximum Torque | 2,500 / 1,050 - 1,350 Nm/rpm |
KOPLING / CLUTCH | |
Tipe/Type | Single dry plate, Diaphragm-spring clutch, Hydraulically operang with air assistance |
Diameter / Diameter | 430 |
TRANSMISI / TRANSMISSION | |
Model | ZF16S2531TO |
BERAT / WEIGHT | |
Berat Kosong Kendaraan / Curb Weight | 10.600 kg |
Berat Total Kendaraan / Gross Vehicle Weight (GVW) | 120.000 kg |
Kapasitas Gardan Depan / Capacity Front Axle | 9.000 kg |
Kapasitas Gardan Belakang / Capacity Rear Axle | 16,000 x 2 kg |
REM / BRAKE | |
Tipe/Type | Full Air Brake |
Rem Kaki / Service Brake | Dual circuit compressed air brake |
Rem Tangan / Hand Brake / Parking Brake | Spring energy, compressed air operating on rear wheels |
Rem Pembantu / Auxiliary Brake | Engine exhaust valve brake, hydraulic retarder |
Anti-lock Braking System (ABS) | yes |
RODA / TYRE | |
Ukuran Ban | 12.00R24 |
Ukuran Velg | 8.5-24 |
SUMBU / AXLE | |
Depan / Front | VGD95 (9 Ton) |
Belakang / Rear | VGD95 (9 Ton) |
LAIN-LAIN / OTHERS | |
Kapasitas Tangki / Fuel Tank Capacity | 860 ltr |
Radius Putar Minimum / Minimum Turning Radius | 12 m |
Daya Tanjak Maksimum / Maximum Gradeability | 30% |
Kecepatan Maksimum / Maximum Speed | 70 km/h |
Kelistrikan / Electrics | Operating voltage: 24 V, negative grounded Starter, Alternator, Batteries, Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Garansi / Warranty | 1 Tahun / 100,000 km |
SASIS & RANGKA / CHASSIS & FRAME | |
Rangka / Frame | Double layer frame |
Ukuran Rangka / Frame Dimensions | 300x90×8 mm |
SUSPENSI / SUSPENSION | |
Depan / Front | 9 layer parabolic leaf spring swith shock absorbers and stabilizer |
Belakang / Rear | 12 layer parabolic leaf springs with shock absorbers and stabilizer |
* Untuk meningkatkan mutu dan penyesuaian dengan perkembangan teknologi, spesifikasi dapat berubah sewaktu-waktu tanpa pemberitahuan. | |
* The manufacturer reserves the right of technical alteration/change for better improvement without prior notice! |
