The positioning of HOWO N series with ultra-high cost performance will bring you more comfort, reliability and income than you expect. The HOWO NX series, produced by Sinotruk, encompasses a range of heavy-duty trucks designed for various applications, including cargo transport, dumping, and liquid transportation. These vehicles are recognized for their robust performance and adaptability to diverse operational needs.
The positioning of HOWO N series with ultra-high cost performance will bring you more comfort, reliability and income than you expect.
The HOWO NX series, produced by Sinotruk, encompasses a range of heavy-duty trucks designed for various applications, including cargo transport, dumping, and liquid transportation. These vehicles are recognized for their robust performance and adaptability to diverse operational needs.
Features and Benefits:
Versatility: The HOWO NX series offers various configurations to cater to specific industry requirements, from construction to logistics.
Performance: Equipped with powerful engines ranging from 280 HP to 480 HP, these trucks ensure efficient operation even under demanding conditions.
Comfort: Modern cabins, such as the H77L, provide ergonomic designs with features like air suspension driver seats and air conditioning, enhancing driver comfort during long hauls.
Durability: Built with robust materials and components, the HOWO NX trucks are designed to withstand rigorous use, ensuring longevity and reduced maintenance costs.
DIMENSI / DIMENSION | |
---|---|
Panjang / Overall Length [OAL] | 9.910 mm |
Lebar / Overall Width [OW] | 2.768 mm |
Tinggi / Overall Height [OH] | 3.748 mm |
Jarak Sumbu / Wheelbase [WB] | 4.600+1.350 mm |
Julur Depan / Front Overhang [FOH] | 1.550 mm |
Julur Belakang / Rear Overhang [ROH] | 1.000 mm |
Jarak Terendah ke Tanah / Minimum Clearance [HH] | 340mm |
Jejak Depan / Front Tread [AW] | 2.030 mm |
Jejak Belakang / Rear Tread [CW] | 1.850 mm |
Ukuran Badan / Body Dimensions | - |
MESIN / ENGINE | |
Model | WD615.47 |
Tipe / Type | 4 Stroke Direct Injection Diesel Engine 6 cylinder in line with water cooling, Intercooler Turbocharged |
Sistem Kontrol Emisi | EURO 2 |
Jumlah Silinder / No. of Cylinders | 6 |
Diameter x Langkah / Bore x Stroke | 126 X 130 mm |
Isi Silinder / Piston Displacement | 9.726 cc |
Tenaga Maksimum / Maximum Power | 371 / 2.200HP/rpm |
Torsi Maksimum / Maximum Torque | 1.500 / 1.100 - 1.600 Nm/rpm |
KOPLING / CLUTCH | |
Tipe/Type | Single dry plate, Diaphragm-spring clutch, Hydraulically operang with air assistance |
Diameter / Diameter | 430 |
TRANSMISI / TRANSMISSION | |
Model | HW19709XST |
BERAT / WEIGHT | |
Berat Kosong Kendaraan / Curb Weight | 17.160 kg |
Berat Total Kendaraan / Gross Vehicle Weight (GVW) | 41.500 kg |
Kapasitas Gardan Depan / Capacity Front Axle | 9.500 x 2kg |
Kapasitas Gardan Belakang / Capacity Rear Axle | 16.000 x 2 kg |
REM / BRAKE | |
Tipe/Type | Full Air Brake |
Rem Kaki / Service Brake | Dual circuit compressed air brake |
Rem Tangan / Hand Brake / Parking Brake | Spring energy, compressed air opera |
Rem Pembantu / Auxiliary Brake | Engine exhaust valve brake |
Anti-lock Braking System (ABS) | No |
RODA / TYRE | |
Ukuran Ban | 12.00R20 |
Ukuran Velg | 8.5-20 |
SUMBU / AXLE | |
Depan / Front | VGD95 (9x2 Ton) |
Belakang / Rear | MCP16ZG (2x16 Ton) |
LAIN-LAIN / OTHERS | |
Kapasitas Tangki / Fuel Tank Capacity | 400 ltr |
Radius Putar Minimum / Minimum Turning Radius | 11.5 m |
Daya Tanjak Maksimum / Maximum Gradeability | 30 % |
Kecepatan Maksimum / Maximum Speed | 70 km/h |
Kelistrikan / Electrics | Operating voltage: 24 V, negative grounded Starter, Alternator, Batteries, Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Garansi / Warranty | 1 Tahun / 100,000 km |
SASIS & RANGKA / CHASSIS & FRAME | |
Rangka / Frame | Double layer frame |
Ukuran Rangka / Frame Dimensions | 300x80×(8+8)mm |
SUSPENSI / SUSPENSION | |
Depan / Front | With hydraulic telescopic double-acon shock absorbers 10 layer Semi-ellipc leaf springs |
Belakang / Rear | 12 layer Semi-ellipc leaf springs with bogie spring and stabilizer |
* Untuk meningkatkan mutu dan penyesuaian dengan perkembangan teknologi, spesifikasi dapat berubah sewaktu-waktu tanpa pemberitahuan. | |
* The manufacturer reserves the right of technical alteration/change for better improvement without prior notice! |
