The positioning of HOWO N series with ultra-high cost performance will bring you more comfort, reliability and income than you expect. The HOWO NX series, produced by Sinotruk, encompasses a range of heavy-duty trucks designed for various applications, including cargo transport, dumping, and liquid transportation. These vehicles are recognized for their robust performance and adaptability to diverse operational needs.
The positioning of HOWO N series with ultra-high cost performance will bring you more comfort, reliability and income than you expect.
The HOWO NX series, produced by Sinotruk, encompasses a range of heavy-duty trucks designed for various applications, including cargo transport, dumping, and liquid transportation. These vehicles are recognized for their robust performance and adaptability to diverse operational needs.
Features and Benefits:
Versatility: The HOWO NX series offers various configurations to cater to specific industry requirements, from construction to logistics.
Performance: Equipped with powerful engines ranging from 280 HP to 480 HP, these trucks ensure efficient operation even under demanding conditions.
Comfort: Modern cabins, such as the H77L, provide ergonomic designs with features like air suspension driver seats and air conditioning, enhancing driver comfort during long hauls.
Durability: Built with robust materials and components, the HOWO NX trucks are designed to withstand rigorous use, ensuring longevity and reduced maintenance costs.
DIMENSI / DIMENSION | |
---|---|
Panjang / Overall Length [OAL] | 8.125 mm |
Lebar / Overall Width [OW] | 2.543 mm |
Tinggi / Overall Height [OH] | 3.160 mm |
Jarak Sumbu / Wheelbase [WB] | 4,325 + 1,350 mm |
Julur Depan / Front Overhang [FOH] | 1.550 mm |
Julur Belakang / Rear Overhang [ROH] | 900 mm |
Jarak Terendah ke Tanah / Minimum Clearance [HH] | 300 mm |
Jejak Depan / Front Tread [AW] | 2.038 mm |
Jejak Belakang / Rear Tread [CW] | 1.866 mm |
Ukuran Badan / Body Dimensions | - |
MESIN / ENGINE | |
Model | MC11.36-50 |
Tipe / Type | 4 Stroke Direct Injection Diesel Engine 6 cylinder in line with water cooling, Intercooler Turbocharged |
Sistem Kontrol Emisi | EURO 5 |
Jumlah Silinder / No. of Cylinders | 6 |
Diameter x Langkah / Bore x Stroke | 120 X 155 mm |
Isi Silinder / Piston Displacement | 10.518 cc |
Tenaga Maksimum / Maximum Power | 360 / 1,900 HP/rpm |
Torsi Maksimum / Maximum Torque | 1,800 / 1,000 - 1,400 Nm/rpm |
KOPLING / CLUTCH | |
Tipe/Type | Single dry plate, Diaphragm-spring clutch, Hydraulically operang with air assistance |
Diameter / Diameter | 430 |
TRANSMISI / TRANSMISSION | |
Model | HW19709XSTL |
BERAT / WEIGHT | |
Berat Kosong Kendaraan / Curb Weight | 9.500 kg |
Berat Total Kendaraan / Gross Vehicle Weight (GVW) | 41.000 kg |
Kapasitas Gardan Depan / Capacity Front Axle | 9.000 kg |
Kapasitas Gardan Belakang / Capacity Rear Axle | 16,000 x 2 kg |
REM / BRAKE | |
Tipe/Type | Full Air Brake |
Rem Kaki / Service Brake | Dual circuit compressed air brake |
Rem Tangan / Hand Brake / Parking Brake | Spring energy, compressed air operating on rear wheels |
Rem Pembantu / Auxiliary Brake | Engine exhaust valve brake |
Anti-lock Braking System (ABS) | No |
RODA / TYRE | |
Ukuran Ban | 12.00R20 |
Ukuran Velg | 8.5-20 |
SUMBU / AXLE | |
Depan / Front | VGD95 (9 Ton) |
Belakang / Rear | MCX16ZG (2x16 To |
LAIN-LAIN / OTHERS | |
Kapasitas Tangki / Fuel Tank Capacity | 400 ltr |
Radius Putar Minimum / Minimum Turning Radius | 11 m |
Daya Tanjak Maksimum / Maximum Gradeability | 30 % |
Kecepatan Maksimum / Maximum Speed | 65 km/h |
Kelistrikan / Electrics | Operating voltage: 24 V, negative grounded Starter, Alternator, Batteries, Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light |
Garansi / Warranty | 1 Tahun / 100,000 km |
SASIS & RANGKA / CHASSIS & FRAME | |
Rangka / Frame | Double layer frame |
Ukuran Rangka / Frame Dimensions | 300x80×(8+8) mm |
SUSPENSI / SUSPENSION | |
Depan / Front | 10 layer Semi-ellipc leaf springs, With hydraulic telescopic double-acon shock absorbers |
Belakang / Rear | 12 layer Semi-ellipc leaf springs, with bogie spring & stabilizer |
* Untuk meningkatkan mutu dan penyesuaian dengan perkembangan teknologi, spesifikasi dapat berubah sewaktu-waktu tanpa pemberitahuan. | |
* The manufacturer reserves the right of technical alteration/change for better improvement without prior notice! |
